The CS1784A USB DVI Dual Link KVMP™ Switch charts a revolutionary direction in KVM switch functionality. It combines the capabilities of a 4-port KVM switch with a 2-Port USB hub, while providing a DVI monitor interface and audio support. Moreover it carries advanced features, such as nVidia 3D Vision ready 120Hz 3D display support, gaming keyboard compatibility and port selection/switching using a mouse, aimed at giving you flexibility, convenience and enjoyment.
Package Contents
1x CS1784A USB DVI Dual Link KVMP™ Switch
4x KVM Cable (DVI-D DL, USB, Audio; 1.8m/6ft)
1x Power Adapter
1x User Instructions
Features
• One USB console controls four computers and two additional USB devices
• 2-port USB 2.0 hub built in
• USB 2.0 compliant
• Full bass response provides a rich experience for 2.1 channel surround sound systems
• Console audio ports on front panel for easy access ideal for IP phone users
• Independent switching of KVM, USB, and Audio focus
• DVI digital and analog monitor support fully compliant with the DVI specifications; also HDCP compliant
• Superior video quality - 2560 x 1600 (DVI Dual Link); 1920 x 1200; DDC2B (DVI Single Link)*
• Supports widescreen resolutions
• Computer selection via front panel pushbuttons and hotkeys
• Multiplatform support - Windows , Mac, and Sun
• Console mouse port emulation / bypass feature supports full mouse driver and multifunction mice
• Video DynaSync™ - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
• HDCP compliant
• Complete keyboard emulation for error-free booting
• Sun/Mac keyboard support and emulation**
• Auto Scan Mode for monitoring all computers
• Firmware upgradeable
* 2560x1600@60Hz (DVI Dual Link); 3840x2400@13Hz (DVI Single Link) only supports specific monitor resolution
** 1. PC keyboard combinations emulate Sun/Mac keyboards, 2. Sun/Mac keyboards only work with their own computers
