Name: Asus PRO WS TRX50-SAGE WIFI, AMD Socket sTR5, ATX, 4xDDR5, 5xPCI Express, 3xM.2 + SATA3 RAID, USB-C, 10GbE+2,5GbE LAN, WiFi 7, Bluetooth 5.4
Brand: ASUS
SKU: 84851

ASUS 90MB1FZ0-M0EAY0

AMD TR5 CEB workstation motherboard, CPU and memory overclocking ready, robust 36 power-stage design, PCIe 5.0 x 16, PCIe 5.0 M.2, 10 Gb and 2.5 Gb LAN, multi-GPU support

• Ready for Advanced AI PC: Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications
• AMD sTR5 socket supports up to 96-core CPUs: Ready for AMD Ryzen™ Threadripper™ PRO 7000 WX-Series Processors and AMD Ryzen Threadripper 7000 Series Processors.
• CPU and memory overclocking: Support for up to 1TB ECC R-DIMM DDR5 memory modules (1DPC)
• Robust power and thermal design: 36 power stages with two 8-pin power connectors for the CPU, massive VRM cooling, chipset and M.2 heatsinks, and M.2 thermal pad.
• Ultrafast connectivity: three PCIe® 5.0 x16 slots, 10 Gb & 2.5 Gb LAN ports, three M.2 slots, front and rear USB 20Gbps Type-C® and SlimSAS NVMe support.
• Server-grade IPMI remote management: hardware and software support for ASUS IPMI expansion cards, plus ASUS Control Center Express software for real-time monitoring and management
• Trusted stability: Validated for extensive compatibility with the latest technologies, an expansive QVL list, and tested for 24/7 operation

Art.nr: 84851

Butikslager

Hyvelgatan

Beställningsvara (ber. 2025-01-09)

Slite Utveckling

Beställningsvara (ber. 2025-01-09)

Fjärrlager

{$antal} {$enhet}

11 590 kr

Produktspecifikation

Egenskaper

Moderkort chipset familj	AMD
Moderkort formfaktor	SSI CEB
Ljudchipp	Realtek ALC1220P
Moderkortets chipset	AMD TRX50
Produktens färg	Svart

Processor

Processorsockel

Socket sTR5

Anslutningsmöjligheter

S/PDIF-utgång	Ja
Antal Ethernet (RJ-45)	2
Antal USB 3.2 Gen 2 (3.1 Gen 2) typ A-portar	6
Antal USB 2.0 anslutningar	2
Antal USB 3.2 Gen 2x2 typ C-portar	1
Uttag för mikrofon/linje in	Ja
WiFi-AP antennuttag	1

Expansionsplatser

PCI Express x16 (Gen 5.x) platser	3
PCI Express x16 (Gen 4.x) platser	2
Antal M.2 (M)-platser	3

Internal I/O

USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar	1
Antal SATA III kontakter	4
ATX strömkontakt (24-pin)	Ja
Ljudanslutning på framsidan	Ja
USB 2.0 anslutning	2
Antal anslutningar för fläktar	4
Antalet COM-anslutningar	1
USB 3.2 Gen 2x2-anslutningar	1
Integrerade SAS-portar	1

Minne

Antal minnesplatser	4
ECC	Ja
Minnestyper som stöds	DDR5-SDRAM

Nätverk

Wi-Fi-standard	Wi-Fi 7 (802.11be)
LAN-styrenhet	Intel I226-LM
Bluetooth	Ja
Wi-Fi	Ja
Bluetooth-version	5.4
Typ av ethernet-gränssnitt	2.5 Gigabit Ethernet, 10 Gigabit Ethernet
Wi-Fi-standarder	Wi-Fi 7 (802.11be)

Lagringskontroll

Lagringsenhetsgränssnitt som stöds	M.2, SATA III
RAID nivåer	0, 1, 5, 10
Antal lagringsenheter som stöds	7
RAID-stöd	Ja
Antalet hårddiskar som stöds	4

Vikt & dimension

Bredd	305 mm
Djup	280 mm
Vikt	2,53 kg

Fabrikat

Tillverkare	ASUS
SKU	90MB1FZ0-M0EAY0
Produktlänk	https://www.asus.com/se/motherboards-components/motherboards/workstation/pro-ws-trx50-sage-wifi/
