Asus PRO WS WRX90E-SAGE SE, AMD Socket sTR5, ATX, 8xDDR5, 7xPCI Express, 4xM.2 + SATA3 RAID, VGA, USB-C, 2x10GbE LAN#1

Asus PRO WS WRX90E-SAGE SE, AMD Socket sTR5, ATX, 8xDDR5, 7xPCI Express, 4xM.2 + SATA3 RAID, VGA, USB-C, 2x10GbE LAN#2

Asus PRO WS WRX90E-SAGE SE, AMD Socket sTR5, ATX, 8xDDR5, 7xPCI Express, 4xM.2 + SATA3 RAID, VGA, USB-C, 2x10GbE LAN#3

Asus PRO WS WRX90E-SAGE SE, AMD Socket sTR5, ATX, 8xDDR5, 7xPCI Express, 4xM.2 + SATA3 RAID, VGA, USB-C, 2x10GbE LAN#4

Asus PRO WS WRX90E-SAGE SE, AMD Socket sTR5, ATX, 8xDDR5, 7xPCI Express, 4xM.2 + SATA3 RAID, VGA, USB-C, 2x10GbE LAN

Name: Asus PRO WS WRX90E-SAGE SE, AMD Socket sTR5, ATX, 8xDDR5, 7xPCI Express, 4xM.2 + SATA3 RAID, VGA, USB-C, 2x10GbE LAN
Brand: ASUS
SKU: 84853

ASUS 90MB1FW0-M0EAY0

AMD sTR5 EEB workstation motherboard, 7 PCIe 5.0 x16 slots, multi-GPU support, robust 32+3+3+3 power-stage design, CPU and memory overclocking ready, 4 PCIe 5.0 M.2 slots, dual 10 Gb LAN, PCIe Q-Release Slim

• AMD sTR5 socket supports up to 96-core CPUs: Ready for AMD Ryzen™ Threadripper™ PRO 7000 WX-Series Processors.
• Ultrafast connectivity: Seven PCIe® 5.0 x16 slots, dual 10 Gb LAN ports, four M.2 slots, two rear USB4® 40Gbps Type-C® and SlimSAS NVMe support.
• CPU and memory overclocking: Support for up to 2 TB ECC R-DIMM DDR5 memory modules (1DPC).
• Robust power and thermal design: 32+3+3+3 power stages with two 8-pin power connectors for the CPU, massive VRM cooling, chipset and M.2 heatsinks with active fans, and M.2 thermal pad.
• PCIe Q-release Slim: Remove the graphics card by directly pulling it up, instead of pressing a PCIe latch.
• Server-grade IPMI remote management and onboard BMC: Hardware and software-level with a dedicated LAN port link to an onboard AST2600 BMC controller, plus ASUS Control Center Express software for real-time monitoring and management.
• Trusted stability: Validated for extensive compatibility with the latest technologies, an expansive QVL list, and tested for 24/7 operation.

Art.nr: 84853

Butikslager

Hyvelgatan

Beställningsvara (ber. 2025-01-09)

Slite Utveckling

Beställningsvara (ber. 2025-01-09)

Fjärrlager

{$antal} {$enhet}

16 890 kr

Produktspecifikation

Egenskaper

Moderkort, chipsetfamilj	AMD
Moderkort formfaktor	EEB
Ljudchipp	Realtek ALC1220P
Moderkortets chipset	AMD WRX90
Produktens färg	Gjuten aluminium, Svart

Processor

Processorsockel

Socket sTR5

Anslutningsmöjligheter

Antal VGA (D-Sub) portar	1
Antal USB 3.2 Gen 2 (3.1 Gen 2) typ A-portar	6
Antal USB 2.0 anslutningar	1

Expansionsplatser

PCI Express x16 (Gen 5.x) platser	7
Antal M.2 (M)-platser	4

Internal I/O

USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar	1
Antal SATA III kontakter	4
ATX strömkontakt (24-pin)	Ja
Ljudanslutning på framsidan	Ja
USB 2.0 anslutning	2
Antal anslutningar för fläktar	5
Antalet COM-anslutningar	1
USB 3.2 Gen 2x2-anslutningar	1

Minne

Antal minnesplatser	8
ECC	Ja
Minnestyper som stöds	DDR5-SDRAM

Nätverk

Wi-Fi	Nej
Typ av ethernet-gränssnitt	10 Gigabit Ethernet, Snabb Ethernet, Gigabit Ethernet

Lagringskontroll

Lagringsenhetsgränssnitt som stöds	M.2, SATA III, SlimSAS
Antal lagringsenheter som stöds	10
RAID-stöd	Ja
Antalet hårddiskar som stöds	4
RAID-nivåer	0, 1, 5, 10

Vikt & dimension

Bredd	305 mm
Djup	330 mm

Fabrikat

Tillverkare	ASUS
SKU	90MB1FW0-M0EAY0
Produktlänk	https://www.asus.com/se/motherboards-components/motherboards/workstation/pro-ws-wrx90e-sage-se/
